| Place of Origin | SHENZHEN |
| Brand Name | OEM |
| Certification | CCC/CE/CUSTOM |
| Model Number | ICP -4 |
Features :
(1) 4" mini touch screen control panel
(2) Quad core Embedded mini touch panel
(3) Running Android 8.1 OS
(4) 480*480 Resolution
(5) Wall mounted , RJ45 port build in
(6) Power supply support AC 110V ~240V , DC 12V and 48V POE
| System | Dimension | 84.5*84.5*36.2mm |
| Display size | 4 inch | |
| CPU | PX30 Quad-core Cortex-A35 | |
| System | Android 8.1 | |
| Resolution | 480*480 IPS | |
| Touch Panel | Cpactive touch panel | |
| RAM | 1G(2G option) | |
| ROM | 8G(16G option) | |
| Network | WIFI | 802.11b/g/n |
| Blue--tooth | BT 4.0 | |
| Ethernet | 10M/100M | |
| Interface | RJ45 | Ethernet interface input (RJ-45 cable) |
| Type C | Type C *1 | |
| RS485 | RS485*1 | |
| Reset | Reset *1 | |
| Speaker | Speaker *1 | |
| Microphone | Microphone *2 | |
| Power suply | POE ,IEEE802.3af | |
| DC 12V /24V | ||
| AC 110~240V , 50HZ | ||
| Customize Function | Light sensor | Light sensor (Option) |
| Temperature and humidity sensor | Temperature and humidity sensor (option) | |
| Zigbee | Tuya zigbee (option) | |
| Media plays | Video | MOV / AVI / WMV / RM / RMVB / 3GP / MKV / MP4 / ASF/ VOB |
| Audio | MP3 / WMA / WAV / AAC / FLAC / OGG | |
| Entertainment | Video / Movie / Music / FM online | |
| Other | Install | In wall & Embedded |
| Color | White color | |
| Working temperature | .-10°~60° | |
| Language | Multi-language optional |
